Radiant Floor Heating Mat

Radiant Floor Heating Mat

$225.00 USD
$225.00 USD $225.00 USD
Sale Sold out
Enjoy an additional ... (Special Offer) off! Final price: ...

Transform any room into a welcoming retreat with this ultra-slim radiant heat floor cable mat, designed for fast, DIY-friendly electric underfloor heating installs. The flexible cable is pre-spaced and fused onto a mesh backing, making installation a breeze—just roll it out and secure it. Perfect for under tile, stone, laminate, or LVP floors, it delivers consistent warmth for bathrooms, living rooms, and beyond. Whether you're adding cozy morning comfort beneath a heated bathroom floor or warming an entire floor with radiant heated floors, this mat delivers efficient radiant heat flooring that’s built to last, backed by a solid 25-year warranty.

Voltage
Length (ft)
Need Help: Call at +(801) 948-7500
Need Quote: Get One Here
Tags: cable, floor, heating, radiant, tools,
View full details
Description Features Specification Product Literature Related Product FAQs Reviews

Description

This electric floor heating mat features a twin-conductor radiant heat floor cable mounted on an adhesive mesh for consistent spacing and fast, accurate installation. It supports 120 V and 240 V systems and outputs 12 W per square foot (approximately 130 W/m² ±10%), based on a recommended 3-inch layout. The thin cable (3.2–4.2 mm in diameter) enables tight 1-inch bends for tailored coverage. Built with fluoropolymer and high-temperature PVC insulation, it’s rated for up to 104 °F (40 °C) ambient conditions and comes with a 10-foot cold lead for easy connection. It meets rigorous safety standards including UL 1673, IEC 60335, and CAN/CSA‑C22.2 (#130‑03), providing reliable performance for your floor heating system.

Features

  • Pre-Spaced Cable on Mesh – Ensures uniform coverage for efficient floor radiant heat
  • 12 W/ft² Heat Output – Delivers consistent warmth for comfortable floors
  • Supports 120 V and 240 V Systems – Compatible with a range of electric underfloor heating needs
  • Flexible, Thin Cable Design – Facilitates tight bends and precise fitting
  • Adhesive Mesh Backing – Speeds installation and maintains spacing accuracy
  • Durable Materials – Fluoropolymer + PVC protect against long-term wear
  • Safe in Warm Environments – Rated for ambient temperatures up to 104 °F
  • Easy Connection – Includes 10-foot cold lead for thermostat or power hookup
  • Certified for Safety – Meets UL, CSA, IEC, and GOST standards
  • Backed by 25-Year Warranty – Confidence-inducing coverage for years to come
  • Ideal for Various Surfaces – Compatible with tile, stone, laminate, and LVP
  • Perfect for Whole-Room or Targeted Use – Whether you're fitting a small heated bathroom floor or a full radiant heated floor

Heated Area Information

Recommended Controls

  • Use Shopify built in products
  • LED WiFi TOUCH Thermostat
  • Programmable TOUCH Thermostat

Specification

Document
Cable Construction Twin-conductor, single-point connection
Rated Voltage 120 V, 240 V
Output 12 W/ft2 (130 W/m2 )±10% (at recommended spacing)
Recommended Spacing 3-inches (76.2 mm)
Bending Diameter 1-inch (25.4 mm)
Cable Diameter 1/8 to 1/6-inch (3.2 mm-4.2 mm)
Conductor Insulation Fluoropolymer
Outer Insulation High Temperature PVC
Max. Ambient Temperature 104°F (40°C)
Min. Installation Temperature 40°F (5°C)
Cold lead (length) 2-wire 16 AWG plus ground braid; 10 feet (3 m)
Standards Meets all test requirements of IEC 60335, CAN/CSA – C22.2 No. 130-03, UL 1673.
Approvals Certified by Intertek SEMKO against relevant IEC / EN 60335, UL and GOST Standard.

Literature

Installation Manual

Product Sheet

Data Sheet

FAQs

What are the differences between the Programmable Touch Thermostat LED Wi-Fi and the Programmable Standard Thermostat?

The Programmable Touch Thermostat features a sleek, low profile design, an LED screen, Wi-Fi, app-based access for control of your radiant floor heating anywhere. Integrated voice control is included and ready to work with Amazon Alexa or Google Assistant. You can also create custom schedules for multiple weeks at a time. In addition, the LED thermostat comes with a 15-foot NTC sensor for precise temperature regulation and can operate on 120V/208V/240V power supplies.

Is connecting the Programmable Touch Thermostat LED Wi-Fi to my radiant heat system difficult?

No. The thermostat’s included app makes installation a breeze. The app will guide you through each step of installation and assure correct installation and operation throughout the life of your floor heating system.

What programmable modes does the thermostat feature?

The Programmable Standard Thermostat includes both operational and safety modes for flexible, reliable control. It offers three operational modes—ambient controlled, floor controlled, or ambient only—allowing you to customize how the temperature is monitored. For added protection and convenience, it also features anti-freeze, open-window detection, floor protection, vacation mode, and a child lock to prevent tampering by curious kids. All modes are simple to navigate on the thermostat’s bright 3.5" color touch screen.
